Xerox Phaser 6128MFP Service Manual

26 Phaser 6128MFP Service Manual
General Information
Maintenance Function
Firmware Update
The Image Processor Board can be updated by customers and service technicians
using a Windows PC or Macintosh with dedicated utilities. Firmware updates are
available at www.xerox.com/office/support.
Detailed procedures are available in “Firmware Update” on page A-10.
Note
Boot Code can be updated via USB port only.
Diagnostics
Two types of diagnostic functions are available:
1. Auto Diagnostics: The printer is checked when it is turned on. It is checked
whether hardware (ROM, RAM, ASIC, etc....) operates properly.
2. Manual Diagnostics: Only qualified service personnel can perform manual
diagnostics using the Service Mode in the Control Panel.
Non-Xerox
To ne r
Cartridge
Manufacturer
Non-Xerox
To ne r
Cartridge
No Life
Tracking
Replace
To ne r
Cartridge
Prints with full
functionality.
Updated Firmware Windows
Via USB/IEEE1284 Via Network (port 9100)
Image Processor Board Available Available
MCU Board
a
a. MCU Board cannot be updated when ROM starts to be used for MCU Board.
Available Available
Toner Cartridge Control Panel Display (continued)
Tone r
Cartridge Control Panel Display Functionality
Normal Status
Life
Warning
Error
End of
Life Error

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
