Phaser 6128MFP Service Manual 2-37
Theory of Operation
Fuser NCS Sensor Warm-Up
The Fuser Non-Contact Sensor at the center of the Heat Roller loses its accuracy
when the temperature of the sensor itself is below -5° C. Therefore, the sensor is
warmed up when the temperature is below -5° C.
Drive Transmission
Main Drive
The Main Drive transmits power as shown in the following diagram.
Main Drive
[ Belt ]
Transfer Belt
[ Name Of Moving Parts ]
Gear P3
Paper Feed Drive
Registration Feeder Chute
Registration Clutch
Rubber Registration Gear
Metal Registration Gear
Gear P2Gear T4
Gear P4
Gear P5
[ Registration Roller ]
[ Metal Registration Roller ]
Feed GearFeed Solenoid
Drive Gear
[ Feed Roller ]
HSG Xerographics (K)
[ Drum (K) ]
HSG Xerographics (C)
[ Drum (C) ]
Imaging Unit Gear 2
HSG Xerographics (M)
[ Drum (M) ]
HSG Xerographics (Y)
[ Drum (Y) ]
Imaging Unit Gear 2
Imaging Unit Gear 1
Imaging Unit
s6128-036
