Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 6-11
Adjustments and Calibrations
Fax/Scanner Parameter Setting
This function reads and writes parameter stored in the Image Processor Board.
Note
Refer to “Chain Link for Fax Parameter Setting” on page A-9 in the Reference
chapter.
To access the Parameter menu:
1. Turn the printer power Off (if the printer is On).
2. Simultaneously press the Up Arrow and Down Arrow buttons and turn on the
printer.
3. The Service Mode menu is displayed.
4. Select Fax/Scanner Diag and press the OK button.
5. Press the Up Arrow or Down Arrow button to find Parameter. Press the OK
button.
Note
Use the Left or Right Arrow button to move the cursor. Use the Up or Down
Arrow button to change the value.
1. Enter the Chain Link number and press the OK button.
2. The value of the parameter is displayed with an *. This is the current value.
3. Enter the appropriate value and press the OK button.
4. Press the Stop button three times to return to the Parameter menu.
5. Press the Up Arrow or Down Arrow button to find Complete. Press the OK
button two times to exit.
Life IU Deve K (Sheet)
Life Manual Feed
Life Tray Sheet
Life Counters (continued)
Counter Name

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
