Xerox Phaser 6128MFP - Humidity Sensor

Phaser 6128MFP Service Manual 8-45
Service Parts Disassembly
Humidity Sensor
PL10.4.20
1. Remove the Left Side Cover (page 8-17).
2. Remove the screw (silver, tap, 8mm) that secures the Humidity Sensor to the
chassis.
3. Unplug the connector (P/J201) and remove the sensor.
s6128mfp-210
