Xerox Phaser 6128MFP - Transfer (Drum

2-8 Phaser 6128MFP Service Manual
Theory of Operation
Transfer (Drum ---> Paper)
The toner image formed on the drum surface is transferred onto the surface of the
paper. The toner is transferred onto the paper in the order of Y, M, C, and K.
Drum Surface
Toner
Electric Potential
on Drum
Developing
Bias
-V
0
s6128-007
s6128-008
Drum Surface
(Black Toner Image)
Drum Surface
(Cyan Toner Image)
Drum Surface
(Magenta Toner Image)
Drum Surface
(Yellow Toner Image)
Paper
Black
Toner Image
Cyan
Toner Image
Magenta
Toner Image
Yellow
Toner Image
