Service Parts Disassembly
Overview
This section contains the removal procedures for field-replaceable parts listed in
the Parts List. In most cases, the replacement procedure is simply the reverse of
the removal procedure. In some instances, additional steps are necessary and are
provided for replacement of the parts. For specific assemblies and parts, refer to
the “Parts List” in Chapter 9.
Standard Orientation of the Printer
When needed, the orientation of the printer is called out in the procedure as an aid
for locating the printer parts. The following figure identifies the Front, Rear, Left,
and Right sides of the printer.
Front
Right
Rear
Left
s6128mfp-301
