Xerox Phaser 6128MFP - Adf

Phaser 6128MFP Service Manual 10-23
Wiring
ADF
PL10.6.6
JADF1
1
2
3
4
5
6
ADF MOT A
ADF MOT B
ADF MOT /B
+3.3VDC
7
8
9
DOC SEN
FEED SEN
COVER SEN
SG
ADF MOT /A
ADF Assembly
PL10.10.1
Connector Board
s6128mfp-228
1
2
3
4
5
6
7
8
9
+3.3VDC
1
2
3
JDFM1
JCV1
1
2
3
4
ADF Motor
ADF Cover
Sensor
M
1
2
3
JDES1
ADF
Document
Sensor
1
2
3
JDS1
ADF Feed
Sensor
A
/A
B
/B
+3.3VDC
+3.3V
P/J1003
ADF Harness Assembly
PL10.10.7
Image Processor
Board
