Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 9-3
Parts List
Using the Parts List
• ID No.: The callout number from the exploded part diagram.
• Name/Description: The name of the part to be ordered and the number of
parts supplied per order.
• Part Number: The material part number used to order that specific part.
• Parts identified throughout this manual are referenced PL#.#.#; For example,
PL3.1.10 means the part is item 10 of Parts List 3.1.
• A black triangle preceding a number followed by a parenthetical statement in
an illustrated parts list means the item is a parent assembly, made up of the
individual parts called out in parentheses.
•The notation “with X~Y” following a part name indicates an assembly that is
made up of components X through Y. For example, “1 (with 2~4)” means part
1 consists of part 2, part 3, and part 4.
• An asterisk (*) following a part name indicates the page contains a note about
this part.
• The notation (NS) next to a part indicates that particular part is not spared,
but contained in a kit or major assembly.
•The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that
connector Jack 1 is attached to one end of the wire harness and connector J2
is attached to the other end that is plugged into P2.
Note
Only parts showing part numbers are available for ordering by support. Parts
not showing part numbers are available on the parent assembly.
Abbreviations
Abbreviation Meaning
CC-ring
EE-ring
KL K-clip
SScrew

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
