Xerox Phaser 6128MFP Service Manual

7-2 Phaser 6128MFP Service Manual
Cleaning and Maintenance
Service Maintenance Procedure
Perform the following procedures whenever you check, service, or repair a printer.
Cleaning the printer, as outlined in the following steps, assures proper operation of
the printer and reduces the probability of having to service the printer in the
future.
The frequency of use, Average Monthly Print Volume (AMPV), type of media
printed on, and operating environment are factors in determining how critical
cleaning the machine is and how often it is necessary. Record the number of
sheets printed.
Recommended Tools
• Toner vacuum cleaner
•Clean water
• Clean, dry, lint-free cloth
• Black light-protective bag
Cleaning
Perform the following general cleaning steps as indicated by the printer’s
operating environment.
Caution
Never apply alcohol or other chemicals to any parts of the printer. Never use a
damp cloth to clean up toner. If you remove the Imaging Unit, place it in a
light-protective bag or otherwise protect it as exposure to light can quickly
degrade performance and result in early failure.
1. Record number of sheets printed.
2. Print several sheets of paper to check for problems or defects.
3. Turn the printer power Off and disconnect the power cord.
4. Remove the Imaging Unit, Fuser, Toner Cartridges, Left and Right Side Covers,
and Rear Cover before cleaning.
5. Clean the Fan.
6. Ensure that all cover vents are clean and free of obstructions.
7. Remove any debris or foreign objects from the Fuser, Transfer Belt, Imaging
Unit, and inside of the printer.
8. Remove and clean the paper trays.
9. Clean all rubber rollers with a lint-free cloth slightly dampened with cold water.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
