Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 1-11
General Information
Specifications
Printer Specifications
Characteristic Specification
Printing Technology Recording System: Tandem electro-photographic system
using OPC Drum and direct transfer by the Transport Belt
Exposure System: 4 semiconductors laser beam
scanning system
Transfer System: Four-color finished toner image is
transferred onto the paper
Fusing System: Thermal fusing system by Free Belt Nip
Fusing (FBNF)
Print Volume Average 450 PV/month
Maximum 40,000 PV/month
Median 300 PV/month
Color Medium Cyan, Magenta, Yellow, and Black Toner Cartridges
Resolution /
Addressability (dpi)
Standard 600 x 600 x 1
Enhanced 600 x 600 x 4
Print-Quality Mode 600 x 600 x 1bit (Standard)
600 x 600 x 4bit (Enhanced)
Average Image
Coverage
Color 5% each CMYK
Mono 5%
Maximum Image
Coverage
240% for all C, M, Y, K combined
Printer Life 100,000 pages
Maximum Duty
Cycle
40,000 pages/month*
Warm-Up Time Less than 30 seconds from Power On
Operating System Windows 2000/ 2003 Server/ XP Pro/ XP/
Vista
Macintosh OS 10.2 or higher
Linux Redhat, SuSe, and TurboLinux 10
Desktop
* Assumes a 30 day month of printing.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
