Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-101
Error Messages and Codes
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Transfer Belt, Fuser, and
Imaging Unit for correct installation.
Are the parts correctly installed?
Go to step 3. Correct any
problems
found.
2 Does the error persist when the
power is turned On?
Go to step 3. Complete.
3 Run the Main Motor test (DO-00) on
(page 4-41).
Does the motor rotate?
Go to step 4. Go to step 5.
4 Check connectors P/J21 and P/J211
between the MCU Board and Main
Motor Assembly.
Are the connectors secure?
Go to step 5. Reconnect the
connectors.
5 Check the Main Drive harness
continuity. Disconnect P/J21 from
the MCU Board and P/J211 from the
Main Drive to check continuity.
Is the harness damaged?
Repair or
replace the
harness
(PL10.8.7).
Go to step 6.
6 Check the Main Drive Assembly for
correct installation.
Is the Main Drive Assembly installed
correctly?
Go to step 7. Reseat the
Main Drive
Assembly
(page 8-58).
7 Check for +24 V at J21 on the MCU
Board.
Is +24 V available at J21-2 and J21-
4 when the Interlock Switch is
closed?
Replace the
Main Drive
Assembly
(page 8-58).
Replace the
MCU Board
(page 8-57).

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
