Xerox Phaser 6128MFP Service Manual

3-106 Phaser 6128MFP Service Manual
Error Messages and Codes
Side Door Open Close Side Door
The Right Side Door Switch indicates the Right Side Door is open. The following
troubleshooting procedure applies to this error.
Applicable Error
• Side Door Open Close Side Door
Initial Actions
• Check the Right Side Door and switch actuator for damage.
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check Interlock Switch operation.
Run the Interlock Switch test (DI-07)
(page 4-36).
Does the Switch operate?
Replace the
MCU Board
(page 8-57).
Go to step 2.
2 Check the Interlock Harness
connections P/J14 and P/J501.
Are the connections secure?
Go to step 3. Secure the
connections.
3 Check continuity of the LVPS Main
Harness. Disconnect P/J14 from the
MCU Board and P/J501 from the
LVPS.
Is the harness damaged?
Repair the
harness.
Go to step 4.
4 Check for +24 V on P44 of the LVPS.
Is there +24 V between P44-1 <=>
ground?
Go to step 5. Replace the
LVPS
(page 8-47).
5 Check the Interlock Switch signal.
Does the voltage between P44-3 <=>
ground change when the switch is
closed?
Replace the
LVPS
(page 8-47).
Replace the
Interlock
Harness
(page 8-52).
6 Replace the Interlock Switch Harness
(page 8-52).
Does the error persist?
Replace the
MCU Board
(page 8-57).
Complete.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
