Xerox Phaser 6128MFP - Internal View

1-6 Phaser 6128MFP Service Manual
General Information
Internal View
1. Fu s e r
2. I m a g i n g U n i t
3. Toner Cartridges
4. Tr a n s f e r B e l t
5. F r o n t C o v e r R e l e a s e
s6128mfp-128
2
1
3
4
5
