Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 6-3
Adjustments and Calibrations
Enabling/Disabling Automatic Color Registration
This procedure provides instructions for how to enable or disable the Automatic
Color Registration function after a new Imaging Unit is installed.
• If the function is set to On, the printer will calibrate the color alignment every
time it detects a new Imaging Unit.
• If the function is set to Off, calibration will not occur. This allows users to save
toner.
To enable or disable the Automatic Color Registration:
1. From the Control Panel, press the System button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press the OK
button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode. Press
the OK button.
4. Press the Up Arrow or Down Arrow button find Adjust Regi. Press the OK
button.
5. Press the Up Arrow or Down Arrow button to turn automatic color
registration On or Off.
Adjusting Color Registration
Color Registration can be automatically or manually adjusted.
Determining the Values
From the lines to the right of the Y (yellow), M (magenta), and C (cyan) pattern,
find the values of the straightest lines.
When “0” is the value nearest the straightest line, you do not need to adjust the
color registration. When the value is not “0,” refer to “Manual Color Registration
Adjustment” on page 6-4.
Auto Adjustment
1. From the Control Panel, press the System button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press the OK
button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode. Press
the OK button.
4. Press the Up Arrow or Down Arrow button find Adjust Color Regi. Press the
OK button.
5. The Auto Adjust menu is displayed. Press the OK button.
6. Are you sure? message is displayed. Press the OK button to start the Auto
Adjustment procedure.
7. The printer starts the auto Color Registration process.
8. When the auto Color Registration is completed, the Ready menu is displayed.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
