Xerox Phaser 6128MFP Service Manual

6-6 Phaser 6128MFP Service Manual
Adjustments and Calibrations
Calibrations
Initializing Print Meter
This process initializes the Print Meter.
1. From the Control Panel, press the System button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press the OK
button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode. Press
the OK button.
4. Press the Up Arrow or Down Arrow button to find Init PrintMeter. Press the
OK button.
5. Are you sure? message is displayed. Press the OK button to start the process.
6. Initialized message is displayed. The Maintenance Mode - Init PrintMeter
menu is displayed when the process is completed.
Initializing NVM (NVRAM)
This process initializes the settings stored in the NVRAM except for the network
settings. The NVRAM is a non-volatile memory that stores the printer settings even
after the power is turned Off. After executing this function and restarting the
printer, all the menu parameters are reset to their default values.
1. From the Control Panel, press the System button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press the OK
button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode. Press
the OK button.
4. Press the Up Arrow or Down Arrow button to find Initialize NVM. Press the
OK button.
5. Are you sure? message is displayed. Press the OK button to start the process.
6. Initializing... --> Initialized messages are displayed.
7. The Maintenance Mode - Initialize NVM menu is displayed when the process
is completed.
8. Turn the printer power Off and back On.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
