Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-113
Error Messages and Codes
Env Sensor Error
The Environmental Sensor has detected temperature error. This troubleshooting
procedure applies to this error.
Applicable Error
• 092-661: Env Sensor Error
Initial Actions
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Humidity/Temp Sensor PL10.4.20
■ Humidity Harness, PL10.4.21
■ MCU Board, PL10.7.7
■ “Map 1 - MCU Board” on page 10-6
■ “Map 3 - Electrical and Drive” on page 10-8
■ “Xerographics” on page 10-18
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Humidity/Temperature
Sensor for correct installation.
Is the Humidity/Temperature Sensor
correctly installed?
Go to step 2. Reseat the
Humidity/
Te mpe ra t ur e
Sensor.
Go to step 2.
2 Does the error still occur when the
printer is turned On?
Go to step 3. Complete.
3 Check connectors P/J20 and P/J201
between the MCU Board and the
Humidity/Temperature Sensor.
Are the connectors securely
connected?
Go to step 4. Reconnect the
connectors.
4 Check the Humidity Harness for
continuity. Disconnect P/J20 from
the MCU Board and P/J201 from the
Humidity/Temperature Sensor.
Is the harness damaged.
Go to step 5. Replace the
Humidity
Harness.
5 Check the Humidity/Temperature
Sensor signal.
Is there +5 V across ground <=> J20-
4 pin on the MCU Board?
Replace the
Humidity/
Te mp era t ur e
Sensor
(page 8-45).
Replace the
MCU Board
(page 8-57).

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
