Xerox Phaser 6128MFP Service Manual

1-2 Phaser 6128MFP Service Manual
General Information
Printer Introduction and Overview
The Xerox Phaser 6128MFP combines a color laser print engine, scanner, copier,
and Fax. The Phaser 6128MFP has a single-pass color laser architecture, which
offers color and mono print speed at 12/16-ppm, and resolutions up to 600 x 600
dots-per-inch (dpi). The printer supports USB 2.0 and 10/100 Base-TX Ethernet
connectivity. The Scanner supports USB Scan to Desktop, Network Scan to FTP,
Network Scan to Server Message Block (SMB), and Network Scan to E-Mail with
resolution up to 1200 dpi and interpolated up to 9600 dpi.
The Phaser 6128MFP provides a 35-sheet Automatic Document Feeder (ADF), a
250-sheet Tray, a manual feed slot supporting single-sheet feed of specialty
media, card stock, and envelopes. The Output Tray holds 150 sheets facedown.
Technical Support Information
The Xerox Service Manual is the primary document used for repairing,
maintaining, and troubleshooting the printer.
To ensure complete understanding of this product, participation in Xerox Service
Training is strongly recommended. To service this product, Xerox certification for
this product is required.
For updates to the Service Manual, Service Bulletins, knowledge base, etc., go to:
• Xerox Global Service Net -https://www.xrxgsn.com/secure/main.p
• Service Partners: http://www.office.xerox.com/partnersl
For further technical support, contact your assigned Xerox Technical Support for
this product.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
