Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 4-9
General Troubleshooting
Service Diagnostic Tests
IIT Diagnostic Tests
Test Control Panel Display Test Description
Board Tests Tests the function of the Fax, ADF, and Scanner boards.
All Test All Test
■ Ready
■ Now checking
■ Check OK or NG
Runs all board tests.
FAX Memory
RTC Test
■ Ready
■ Now checking
■ Check OK or NG
This test checks the Real Time Clock
chip. Run this test when error 117-
365 occurs.
FAX Flash Test
■ Ready
■ Now checking
■ Check OK or NG
Performs write/read/verification on
the FAX Flash memory. Run this test
when error 017-971, 017-972, 017-
973, 017-974, or 117-344 occurs.
SDRAM Test
■ Ready
■ Now checking
■ Check OK or NG
Performs write/read/verify on the
SRAM. Run this test when error 117-
311, 117-362, 117-363, 133-254,
017-970, 033-503, or 033-787
occurs.
I/F Test
FAX CardTest
■ Ready
■ Now checking
■ Check OK or NG
This test checks communication with
the FAX Board. Run this test when
FAX related errors occur.
AFE Serial Test
■ Ready
■ Now checking
■ Check OK/Check NG
This test checks communication with
the AFE serial interface. Run this test
when FAX or Scanner related errors
occur.
FPGA IIT I/F
Test
■ Ready
■ Now checking
■ Check OK/Check NG
This test checks communication with
the IIT interface. Run this test when
FAX or Scanner related errors occur.
Fire3 Test
Fire3 IJAC Test
■ Ready
■ Now checking
■ Check OK or NG
This test checks the Fire3 IJAC. Run
this test when FAX or Scanner related
errors occur.
Fire3 IBIG Test
■ Ready
■ Now checking
■ Check OK or NG
This test checks the Fire3 IBIG. Run
this test when FAX or Scanner related
errors occur.
Relay/Signal
Test

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
