Xerox Phaser 6128MFP Service Manual

4-10 Phaser 6128MFP Service Manual
General Troubleshooting
Relay Test Switches the relay circuit between
the Fax and telephone lines.
Relay Toggle
Test
Relay Toggle Test
■ Time [10ms]:0000
■ Now Switching
This test switches the relay circuit
between the Fax and telephone lines
at a set cycle mulitple. Cycle value
range is 50 to 9999, and the toggle
interval is 10ms. (Time = CV x 10ms).
Data 1: Default is 2 seconds.
Relay Set Test Relay Set Test
■ Set ON [OPEN]
■ Set OFF [CLOSE]
■ Complete
This test connects the relay circuit to
the Fax or telephone line.
■ Set ON: Connect the Fax line.
■ Set OFF: Connect the telephone
line.
Hook Test This test switches the telephone line
between on and off-hook states.
Hook Toggle
Test
Hook Toggle Test
■ Time [10ms]:0000
■ Now Switching
This test switches the telephone line
between on and off-hook states at a
set cycle. Cycle value range is 50 to
9999, and the toggle interval is
10ms. (Time = CV x 10ms).
Data 1: Default is 2 seconds.
Hook Set Test Hook Set Test
■ Set ON
■ Set OFF
■ Complete
This test switches the telephone line
between on or off-hook states.
■ Set ON: Connect the on-hook
circuit.
■ Set OFF: Connect the off-hook
circuit.
Single Tone
Send
Single Tone Send
■ 0Hz, 400Hz, 462Hz,
1100Hz, 1300Hz,
1500Hz, 1650Hz,
1850Hz, 2100Hz,
500Hz, 600Hz, 900Hz,
1000Hz
■ Now Sending Signal
■ Complete
Checks the tone output for each
single tone for tone dialing.
DTMF Send DTMF Send Unplug phone line before performing
these tests to prevent a call
connection.
DTMF
Continuous
DTMF Continuous
■ DTMF: 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, A, B, C, D, *, #
■ Now Sending Signal
■ Complete
This test checks the tone output for
all touch tones for tone dialing.
DTMF
Individually
DTMF Individually
■ 0000000000000000
■ Now Sending Signal
■ Complete
This test checks the tone output for
16 key numbers on the LCD.
Use to transmit the specified signal
separately 3 seconds after off hook.
After 16-digit signal is transmitted,
the signal stops, but off hook status
continues.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
