Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 4-11
General Troubleshooting
Dial Pulse
Send
Dial Pulse Send Unplug phone line before performing
this test to prevent a call connection.
DP10
Individually
DP10 Individually
■ 0000000000
■ Now Sending Signal
■ Complete
This test checks the 10PPS pulse
output for one of the 10 key
numbers set on the LCD.
Use to transmit the specified signal
separately 3 seconds after off hook.
After 10-digit signal is transmitted,
the signal stops, but off hook status
continues.
DP20
Individually
DP20 Individually
■ 0000000000
■ Now Sending Signal
■ Complete
This test checks the 20PPS pulse
output for one of the 10 key
numbers set on the LCD.
Use to transmit the specified signal
separately 3 seconds after off hook.
After 10-digit signal is transmitted,
the signal stops, but off hook status
continues.
Ring Back
Tone
Ring Back Tone
■ Now Sending Signal
Checks the tone output signals for
the ring back tone at 400Hz + 16Hz.
Data Send Data Send
■ V.34 33600bps
■ V.34 31200bps
■ V.34 28800bps
■ V.34 26400bps
■ V.34 24000bps
■ V.34 21600bps
■ V.34 19200bps
■ V.34 16800bps
■ V.34 14400bps
■ V.34 12000bps
■ V.34 9600bps
■ V.34 7200bps
■ V.34 4800bps
■ V.34 2400bps
■ V.29 9600bps
■ V.29 7200bps
■ V.27ter 4800bps
■ V.27ter 2400bps
■ V.21 300 bps
■ V.17 14400bps
■ V.17 12000bps
■ V.17 9600bps
■ V.17 7200bps
■ Pattern All 0
■ Pattern All 1
■ Pattern 0101010101
■ Pattern 0000100001
■ Pattern 1111011110
■ Now Sending Signal
Checks the modem output for each
of the transmission rates in
compliance with ITU-T
recommendations.
Data Sending Patterns:
■ All 0
■ All 1
■ 0101010101
■ 0000100001
■ 11101110
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
