Xerox Phaser 6128MFP Service Manual

4-12 Phaser 6128MFP Service Manual
General Troubleshooting
Line Voltage Line Voltage
■ Value[1.0V]: 000
■ Now Sampling
This test measures the telephone
line voltage. Line voltage varies
country to country. Typically 48V in
the US.
Line Current Line Current
■ Value[1.1mA]: 000
■ Now Sampling
This test measures the telephone
line amperage. The minimum current
in the US is 20mA.
Information Displays the scan count for platen and ADF scans.
Scan Counter
Scan Counter FB:0x00000000
ADF:0x00000000
Displays the scan counter value.
■ FB: Platen scans.
■ ADF: ADF scans.
Scanner Maintenance
White Balance White Balance Enables automatic calibration of the
correction value for platen (FB) and
ADF scanning.
Auto Adjust
(FB)
Auto Adjust (FB)
■ Ready
■ Now Adjusting
■ Adjust OK or NG
Use to configure the White Balance
by correcting C2 value for document
glass with auto-adjustment.
Auto Adjust
(ADF)
Auto Adjust (ADF)
■ Ready
■ Now Adjusting
■ Adjust OK or NG
Use to configure the White Balance
by correcting C2 value for ADF with
auto-adjustment.
Shading
Parameter
■ Coeff FB
■ Coeff ADF [Hex]: 00
■ Target[Hex]:*00
Displays the values stored for
shading correction (R, G, B, and Grey)
applied to platen, ADF, and target
scans. Adjust the white balance
value read from the white reference
plate. Changing these values affects
image quality.
Registration
Parameter
■ Regi FB Lead [Hex]:
00
■ Regi FB Side [Hex]: 00
■ Regi ADF Lead [Hex]:
00
■ Regi ADF Side [Hex]:
00
Adjusts the side and lead
registrations during document
scanning. Changing this value
affects image quality.
Auto
Registration
■ Set ON
■ Set OFF
■ Complete
Sets whether or not to auto-adjust
the registration.
Sensor
Parameter
Feed Sensor V Adjusts the Feed sensor output
value.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
