Xerox Phaser 6128MFP Service Manual

4-4 Phaser 6128MFP Service Manual
General Troubleshooting
Service Diagnostics
The Phaser 6128MFP printer has built-in diagnostics to test Sensors, Clutches,
Solenoids, display printer status, and provides some NVRAM access. Use these
tests to diagnose problems and isolate which component or sub assembly part
needs replacement.
If confronted with an error that requires more than a cursory investigation to clear
or when directed by a troubleshooting procedure, use the diagnostic tests to
exercise selected sub-assemblies or parts in the vicinity of the reported error.
Diagnostic tests are controlled from the Control Panel and are described in detail
in “Service Diagnostic Tests” on page 4-9.
Entering Service Diagnostics Mode
1. Turn the printer power Off.
2. Press and hold the Up and Down Arrow buttons simultaneously and turn the
printer power On.
3. Release the Arrow buttons when Please Wait... message is displayed.
4. The Service Mode menu appears with FAX/Scanner Diag and Printer Diag
and test groups listed to indicate the printer is in service mode.
Using Service Diagnostics
Two test groups, FAX/Scanner Diag and Printer Diag are avilable to test
components of the ADF, Scanner, Fax, or printer. Most of the diagnostic tests are
straightforward and require no additional explanation, but there are some that
require specific conditions be met to achieve meaningful results. These
instructions cover each of the test groups, listing special instructions, conditions, or
other information necessary to successfully interpret the results of the diagnostic
tests.
Diagnostic tests are arranged in a menu structure. Use the Arrow buttons to scroll
through the menus and highlight the desired test. The OK button runs the test. To
switch between test groups, exit the current diagnostics mode and return to the
Service Mode menu.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
