3-116 Phaser 6128MFP Service Manual
Error Messages and Codes
RAM Errors
The controller has detected a RAM access error. The following troubleshooting
procedure applies to these errors.
Applicable Errors
• 116-316: RAM Error
• 116-320: RAM Error
Initial Actions
• Cycle printer power.
• If the problem persists, follow the procedure below.
2 Reseat the Memory Card.
Does the error persist?
Replace the
Memory Card,
then go to step
3.
Complete.
3 Reseat all connections on the Image
Processor Board.
Does the error persist?
Replace the
Processor Board
(page 8-41).
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL10.6.6
■ Memory Card, PL10.6.8
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Memory Card. If the
Memory Card was recently installed,
it may not be compatible.
Is the Memory Card compatible?
Go to step 2. Replace the
Memory Card.
2 Check the Memory Card for correct
installation.
Is the Memory Card correctly
installed?
Go to step 3. Reseat the
Memory Card.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
To Next Page
