Xerox Phaser 6128MFP - Media Feed

Phaser 6128MFP Service Manual 10-15
Wiring
Media Feed
MCU Board
PL10.7.7
Left Side Harness Assembly
PL10.4.18
9
10
11
3
2
1
PULL UP +3.3VDC
SG
PAPER EMPTY SENSED (L) +3.3VDC
Tray 2 No Paper Sensor
PL3.2.13
P/J234
I/L +24VDC
CST FEED CL ON (L) +24VDC
2
1
1
2
1
2
MPT Feed Solenoid
PL10.4.11
P/J231
P/J23
+3.3VDC
6
7
8
K Sensor Registration Clutch Harness Assembly
PL10.8.9
PAPER EMPTY SENSED (H) +3.3VDC
SG
P/J233
3
2
1
PULL UP +3.3VDC
Tray 1 (MPT) No Paper Sensor
PL3.2.13
3
4
5
REGI SENSED (L) +3.3VDC
SG
3
2
1
PULL UP +3.3VDC
Registration Sensor
PL3.2.13
P/J232
P/J26
4
5
I/L +24VDC
REGI CL ON (L) +24VDC
2
1
1
2
P/J262
Drive Clutch Assembly
PL10.4.1
s6128mfp-220
Interlock
+24VDC
+3.3VDC
+3.3VDC
