Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 4-53
General Troubleshooting
2. Cannot dial.
Cause: No connection. Incorrect setup of dial type and/or line type.
Corrective Action: Reconnect the telephone line. Reset the dial type and/or
line type to correct the settings.
Reception Fault
1. Cannot Receive.
a. Answering mode is incorrect.
Cause: The answering mode is set to TEL Mode in the Fax Settings: System --
> Admin Menu --> Fax Settings --> Ans Select.
Corrective Action: Change the answering mode from TEL Mode to other
mode (i.e., FAX Mode, TEL/FAX Mode, Ans/FAX Mode, DRPD Mode...).
b. Fax memory is full.
Cause: An attempt was made to send document data in excess of the
available memory capacity.
Corrective Action: On the receiving side, wait until the current fax job is
printed completely.
c. The printer displays some fault messages.
Cause: A fault occurred in the printer.
Corrective Action: Refer to the appropriate fault error procedures to resolve
the problem.
d. Distinctive ring pattern detection fails.
Cause: The distinctive ring pattern set for the DRPD mode is incorrect
(applicable only in USA and Canada).
Corrective Action: Check the ring pattern provided by the telephone service
provider, and select the correct pattern for fax.
e. Cannot detect Calling Tone (CNG) signal.
Cause: Communication fails in TEL/FAX mode or Ans/FAX mode.
Corrective Action: Ground the printer properly.
f. Cannot detect off-hook.
Cause: Communication fails in TEL/FAX mode or Ans/FAX mode.
Corrective Action: Set Extel Hook Thresh to Higher: System --> Admin Menu -
-> Fax Settings --> Extel Hook Thresh.
Note
Off-hook detection is indicated by a change in the Control Panel display
on receipt of an off-hook signal from an external telephone.
2. Problem with printing quality, such as corrupted image, lines in image, or top/
bottom cut off.
a. If copy function is normal.
Cause: Degraded telephone line connection is caused by noise, etc., or a fault
is sending Fax’s scanner.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
