Xerox Phaser 6128MFP - Jam at Registration Roller

3-50 Phaser 6128MFP Service Manual
Error Messages and Codes
Jam at Registration Roller
The Registration Sensor is not turned On within the specified time. The following
troubleshooting procedure applies to these errors.
Applicable Error
• Jam at Regi Roll Open Front Cover
Initial Actions
• Check the media path for obstructions or debris.
• Check the condition of the Registration Sensor Actuator.
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Clutch, PL3.1.1
■ Registration Roller Actuator, PL3.2.8
■ Registration Roller, PL3.2.9
■ Registration Roller Metal, PL3.2.10
■ Registration In Actuator, PL3.2.11
■ Registration Sensor, PL3.2.13
■ Transfer Belt, PL6.1.7
■ Main Drive Assembly, PL7.1.2
■ Left Side Harness, PL10.4.18
■ MCU Board, PL10.7.7
■ Main Motor Harness, PL10.8.7
■ Registration (KSNR) Harness, PL10.8.9
■ “Map 2 - Feed and Laser Unit” on page 10-7
■ “Map 4 - Imaging” on page 10-9
■ “Media Feed” on page 10-15
■ “Main Drive” on page 10-16
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the media condition.
Is the media damaged or damp?
Replace the
media.
Go to step 2.
2 Check the Front Cover latch.
Does the Front Cover latch correctly?
Go to step 3. Repair or
replace the
Front Cover
(page 8-15).
3 Check the Transfer Belt.
Is the Transfer Belt damaged or
misaligned?
Repair or
replace the
Transfer Belt
(page 8-103).
Go to step 4.
