Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 3-49
Error Messages and Codes
14 Check connectors P/J23 and P/J232
between the MCU Board and
Registration Sensor.
Are the connectors secure?
Go to step 15. Reconnect the
connectors.
15 Check Left Side Harness continuity.
Disconnect P/J23 from the MCU
Board and P/J232 from the
Registration Sensor.
Is the harness damaged?
Repair or
replace the
harness
(PL10.4.18).
Go to step 16.
16 Check for +3.3 V at J23 of the MCU
Board.
Is there +3.3 V across ground <=>
J23-3 pin on the MCU Board?
Go to step 17. Replace the
MCU Board
(page 8-57).
17 Check Registration Sensor signal.
Does the voltage between ground
<=>J23-5 on the MCU Board change
when the Registration Actuator In is
used to block the sensor?
Replace the
MCU Board
(page 8-57).
Replace the
Registration
Sensor
(page 8-29).
18 Check connectors P/J26 and P/J262
between the MCU Board and
Registration Clutch.
Are the connectors secure?
Go to step 19. Reconnect the
connectors.
19 Check KSNR Registration Clutch
harness continuity.
Disconnect P/J26 from the MCU
Board and P/J262 from the
Registration Clutch.
Is the harness damaged?
Repair or
replace the
harness
(PL10.8.9).
Go to step 20.
20 Check for +24 V at J26 of the MCU
Board.
Is there +24 V between ground <=>
J26-4 on the MCU Board when the
Interlock Switch is closed?
Go to step 21. Replace the
MCU Board
(page 8-57).
21 Check Registration Clutch resistance.
Disconnect P/J262 from the Feed
Solenoid
Is the resistance across J262-1 and
J262-2 about 280 Ohms?
Replace the
MCU Board
(page 8-57).
Replace the
Registration
Clutch
(page 8-35).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
