Xerox Phaser 6128MFP Service Manual

3-48 Phaser 6128MFP Service Manual
Error Messages and Codes
5 Check the Manual Feed Actuator for
damage or misalignment. Remove
the Lower Chute (PL3.2.27) to
examine the actuator.
Is the actuator damaged or
misaligned?
Repair or
replace the
manual Feed
Actuator In
(page 8-28).
Go to step 6.
6 Run the Manual Feed Sensor test
(DI-0) (page 4-39).
Use the actuator to toggle the
sensor output.
Does the sensor operate?
Go to step 7. Go to step 10
7 Run the Registration Clutch test
(DO-00 and DO-29) (page 4-48).
Does the Registration Clutch and
Registration Rollers operate?
Go to step 8. Go to step 18.
8 Check the Registration Roller
Actuator for damage or
misalignment. Remove the Lower
Chute (PL3.2.27) to examine the
actuator.
Is the actuator damaged or
misaligned?
Repair or
replace the
Registration
Roller Actuator
(PL3.2.8)
Go to step 9.
9 Run the Registration Sensor test (DI-
2) (page 4-35).
Use the Registration Actuator In to
toggle the sensor output.
Does the sensor operate?
Replace the
MCU Board
(page 8-57).
Go to step 14.
10 Check connectors P/J23 and P/J233
between the MCU Board and
Manual Feed Sensor.
Are the connectors secure?
Go to step 11 Reconnect the
connectors.
11 Check Left Side Harness continuity.
Disconnect P/J23 from the MCU
Board and P/J233 from the Manual
Feed Sensor.
Is the harness damaged?
Repair or
replace the
harness
(PL10.4.18).
Go to step 12.
12 Check for +3.3 V at J23 on the MCU
Board.
Is +3.3 V available between J23-6
<=> ground?
Go to step 13. Replace the
MCU Board
(page 8-57).
13 Check Manaul Feed Sensor signal.
Does the voltage between ground
<=>J23-8 on the MCU Board change
when the actuator blocks the
sensor?
Replace the
MCU Board
(page 8-57).
Replace the
Manual Feed
Sensor
(page 8-27).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
