4-50 Phaser 6128MFP Service Manual
General Troubleshooting
Drum Erase Lamp (K)
Install the safety interlock override to provide power to the device under test.
1. Enter Service Diagnostics (page 4-4).
2. Open the Front Cover.
3. Remove the Imaging Unit (page 8-8).
4. Perform the Drum Erase Lamp K test: Engine Diag > Motor Test > Drum Erase
Lamp K (DO-3d).
5. Verify that the Lamp is operating.
7. Press the Stop button to stop the Drum Erase Lamp K test.
