Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual 4-27
General Troubleshooting
DO-5, DO-6, DO-7 Sub Motor
DO-a Color Mode Switching Solenoid
DO-b, DO-c Feed Roller (half, full rotation)
DO-1e, DO-1f Fan (high, low speed)
DO-21, DO-23, DO-25,
DO-27
Toner Motors (Y,M,C,K)
DO-29 Registration Clutch
DO-2f Feed Solenoid
DO-3d K Drum Erase Lamp
DO-3f C, M, Y Drum Erase Lamps
NVM Settings Edits, saves, loads, and prints NVM information.
Edit NVM
■ Ad0000=00000000*
■ Please wait
Displays current NVM values. Use
this function to edit NVM
information.
Save NVM to
ESS
Save NVM
■ Save NVM MCU ->
ESS OK?
■ Saved
■ Please wait
Saves MCU NVM to the Controller
Board.
Load NVM
from ESS
■ Load NVM MCU ->
ESS OK?
■ Processing
■ Loaded
■ Please wait
Loads MCU NVM from the Controller
Board into the replacement MCU
Board.
Print NVM Info
■ Processing
■ Please wait
Prints NVRAM information saved in
the Controller.
Print Info Provides printer configurations and settings information.
Info Page
■ Ready
■ Processing
Prints the software version of the
printer controller. Use this function
to verify the printer configuration.
The Configuration Page contains:
■ Engine installation unit
information
■ Standard Tray
■ Optional Tray (displaying version)
■ Optional Duplex Unit (displaying
version)
■ Engine ROM Revision No.
■ MCU NVM Revision No.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
