Xerox Phaser 6128MFP Service Manual

4-26 Phaser 6128MFP Service Manual
General Troubleshooting
Engine Test ■ Start
■ Check OK or NG
Communication test with the print
engine. Run this test when the 024-
371 error occurs. Test result: NG (Go
to FIP.) OK (cycle main power.)
ConfigROM
Test
■ Start
■ Check OK or NG
Communication test with the
ConfigROM and the FPGAregister.
READ ROM
Revision No
■ Start
■ Check OK or NG
This test checks communication with
the ConfigROM. The revision number
is read several times.
Engine Diag Tests for print engine components.
Sensor Test
■ Digital Input
■ Code H 0 or 1
At the start of the test,
0 is displayed. This
number counts up when
a sensor is turned On
from Off to indicate
proper operation
These tests check whether the
sensors operate normally. The Sensor
Test is performed for all the
components. Press the OK button
twice to run the selected test. Exit
the Sensor Test by pressing the Stop
button. The display returns to the
Service Mode menu.
NOTE:
During the Sensor Test, no other
diagnostic. functions can be
performed. The printer only accepts
DI components and exit commands.
The device code for each component
is listed below.
Code Component
DI-0 Manual Feeder Sensor
DI-1 No Paper Seneor
DI-2 Registration Sensor
DI-3 Exit Sensor
DI-4 K Mode Sensor
DI-6 Side Switch
DI-7 Interlock Switch
Motor Test These tests check whether the
sensors operate normally. The Sensor
Test is performed for all the
components. Press the OK button
twice to run the selected test. Exit
the Sensor Test by pressing the Stop
button. The display returns to the
Service Mode menu.
NOTE:
During the Sensor Test, no other
diagnostic. functions can be
performed. The printer only accepts
DO components and exit commands.
The device code for each component
is listed below.
Code Component
DO-0, DO-1, DO-2 Main Drive Motor
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
