Xerox Phaser 6128MFP Service Manual

4-28 Phaser 6128MFP Service Manual
General Troubleshooting
Print Settings ■ Ready
■ Processing
Prints the configured settings
through the Control Panel.
The Print Settings page contains:
■ Serial No.
■ HexDump On/Off Information
■ Tone Correction On/Off
Information
■ Color Print Count
■ B/W Print Count
■ Total Pr in t Co un t
■ Color Backup Count
■ B/W Backup Count
■ Total Backup Count
■ Color Error Count
■ B/W Error Count
Installation Provides printer installation information.
Serial No.
■ HATxxxxxx
or
■ HARxxxxxx
Displays the 6 digit Serial Number.
This value is read-only.
Tone
Correction
Tone Correction
■ ON *
■ OFF
Controls TRC in conjunction with
process control to keep density
constant. Turn Off tone correction
when correction exceeds the limit
due to machine-to-machine
variation. Sets the printer Tone
Correction mode On/Off.
NOTE: Note:
When the Tone Correction
has been changed, an “*” is displayed
next to the text.
Display
Counter
Not used in this printer.
Hex Dump
■ OFF *
■ ON
Sets HexDump On/Off. Used to
analyze received data in case of an
error. Setting Hex Dump to On
enables printing of received data via
[Info Page] under [Print info].
Pixel Counter
■ Y: nn.n
■ C: nn.n
■ M: nn.n
■ K: nn.n
Displays the ratio (% used) of the
number of pixel per C/M/Y/K counted
by the Controller to A4 size area
except 4 mm area from the edge on
the last page print.
■ 100% = empty Toner Cartridge
The value is rounded off to one
decimal place.
For B/W print, only K is displayed.
The ranges are from 0-100% for
each color (CMYK).
Configuration Not used in this printer.
Counter Type Not used in this printer.
Print Counter Numeric counts of activity.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
