Xerox Phaser 6128MFP Service Manual

4-30 Phaser 6128MFP Service Manual
General Troubleshooting
Copy Counter
MtoB
■ OK?
■ Processing
■ Copied
Copies the values from Master NVM
to Backup NVM on the Controller
Board.
■ Device-specific information called
“Personal info” in the first 128 Byte
■ PV counter master
■ Printer counter master
Copy Counter
BtoM
■ OK?
■ Processing
■ Copied
Copies the values from Backup NVM
to Master NVM on the Controller
Board.
■ Device-specific information called
“Personal info” in the first 128 Byte
■ PV counter backup
■ Printer counter backup
Clear All NVM
■ OK?
■ Processing
■ Initialized
Clears all Controller Board NVM of
the Controller.
Clear Job
History
■ OK?
■ Processing
■ Initialized
Deletes the job history data from
Controller Board NVM.
Clear
Auditron PV
Clears print volume (PV) or Print
Auditron values.
Test Print Test prints for troubleshooting the printer. See Chapter 5 for
examples and descriptions of test prints.
No Image IOT
■ Ready
■ Processing
Prints a blank page.
Pattern IOT
■ Ready
■ Processing
Prints the Engine Test print at 600
DPI. This page isolates the print
engine (IOT) from the I/P Board.
Grid 2
■ Ready
■ Processing
Prints a built-in grid pattern. This
print isolates ESS function.
Cyan 20%
■ Ready
■ Processing
Prints 20% density pattern of cyan.
Magenta 20%
■ Ready
■ Processing
Prints 20% density pattern of
magenta.
Yellow 20%
■ Ready
■ Processing
Prints 20% density pattern of yellow.
Black 20%
■ Ready
■ Processing
Prints 20% density pattern of black .
CMY 20%
■ Ready
■ Processing
Prints 20% density pattern of cyan,
magenta, and black combined.
Gradation
■ Ready
■ Processing
Prints a pattern in which the density
of each cyan, magenta, yellow, or
black is varied from 0-100%.
Tone r Pa llet
Check
Toner Pallet Check Prints a pattern of 100% density of
each color.
Test Control Panel Display Test Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
