3-42 Phaser 6128MFP Service Manual
Error Messages and Codes
6 Check No Paper Sensor signal.
Does the voltage between ground
<=>J23-8 on the MCU Board change
when the actuator blocks the
sensor?
Replace the
MCU Board
(page 8-57).
Replace the
Manual Feed
No Paper
Sensor
(page 8-28).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
