Xerox Phaser 6128MFP Service Manual

3-136 Phaser 6128MFP Service Manual
Error Messages and Codes
• 035-779: Fax Communications Error
• 133-231: Fax Communications Error
• 133-234: Fax Error
• 133-235: Fax Error
• 116-396: Scan Error
• 116-987: Scan Error
• 116-397: Controller Error
• 116-398: Controller Error
• 117-322: Error (SYSMGR Task Error)
• 117-328: Error (MSCAN Task Error)
• 117-335: Error (DFAX Task Error)
• 117-336: Error (Pull Task Error)
• 117-337: Error (IITTX Task Error)
• 117-340: Error (Hook Task Error)
• 117-348: Error (IITRX Task Error)
• 117-349: Error (SCANMGR Task Error)
• 117-350: Error (Task Initialize Error)
• 117-362: EEPROM Error
Initial Actions
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board (PL10.6.6)
“System Control” on page 10-22
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Print any files stored in memory,
then cycle system power.
Does the error persist?
Go to step 2. Complete.
2 Check the country setting: System >
Admin Menu > Fax Settings >
Country.
Is the country setting correct?
Go to step 3. Correct the
country
setting.
3 Reseat IIT connections on the I/P
Board, then cycle system power.
Does the error persist?
Replace the I/P
Board
(page 8-41).
Complete.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
