Phaser 6128MFP Service Manual 4-7
General Troubleshooting
Diagnostic Menu Map Page 1
Interrupt
Printing
Clear All
Stop
123
456
789
*
0#
// C
Start
Help
ABC DEF
MNOJKLGHI
WXY
Dial Pause
Machine Status
Language
Job Status
Features
Services Home
TUVPRS
Log In/Out
Printer Diag.
ESS Diag.
Engine Diag.
Print Info
Installation
Test Print
Parameter
Exit Mode
s6128mfp-302
To access the Service Diagnostics Menu:
1. Turn off the power.
2. Turn on the power while holding down
the Up Arrow and Down Arrow buttons.
3. Release the buttons when
“Please Wait...” is displayed.
Serial No.
HexDump
Tone Correction
Pixel Counter
Configuration
Counter Type
Print Counter
CopyCounter MtoB
CopyCounter BtoM
Clear All NVM
Clear JobHistory
Clear AuditronPV
FullColor
Color 1
Color 2
B/W
Total
FullColor Backup
Color 1 Backup
Color 2 Backup
B/W Backup
Total Backup
FullColor Error
Color 1 Error
Color 2 Error
B/W Error
FullColor
Color 2
B/W
Total
FullColor Backup
Color 2 Backup
B/W Backup
Total Backup
FullColor Error
Color 2 Error
B/W Error
Color
B/W
Total
Color Backup
B/W Backup
Total Backup
Color Error
B/W Error
SMB/FTP
Email
SMB/FTP Backup
Email Backup
SMB/FTP Error
Email Error
Slow Scan KtoP
Slow Scan 600M
Slow Scan 600Y
Slow Scan 600C
Fast Scan KtoM
Fast Scan KtoY
Fast Scan KtoC
Fast Scan M-Feed
Fast Scan Tray
Fast Scan 2 KtoM
Fast Scan 2 KtoY
Fast Scan 2 KtoC
Life Y Toner
Life M Toner
Life C Toner
Life K Toner
Life Fuser Sheet
Life Print Sheet
Life DTB Waste
Life YWasteToner
Life MWasteToner
Life CWasteToner
Life KWasteToner
Life IU Y Time
Life IU M Time
Life IU C Time
Life IU K Time
Life IU Xero
Life IU Deve K
Life Manual Feed
Life Tray Sheet
Print
No Image IOT
Pattern IOT
Grid2 ESS
Cyan20% ESS
Magenta20% ESS
Yellow20% ESS
Black20% ESS
CMY20% ESS
Gradation ESS
TonerPalletCheck
ContaminationChk
FlashROM Test
EEPROM Test
DRAM Test
MAC+PHY Test
Engine Test
Edit NVM
SaveNVM to ESS
LoadNVM from ESS
Initialize Slave
Print Service
Copy Service
FAX Service
Scan Service
Print NVM Info
Config ROM Test
Sensor Test
Motor Test
NVM Settings
Info Page
Complete Exit
Print Settings
