Xerox Phaser 6128MFP Service Manual

1-8 Phaser 6128MFP Service Manual
General Information
1. Function Select
buttons
Press to use the Copy, Fax, Email, and Scan
menus on the display screen.
2. Display Indicates messages, menus, and toner levels.
3. Arrow buttons Scroll through the menus. The Back Arrow
button also displays the Walk-Up Features
menu.
4. Job Status button Press to check active job status.
5. System button Switches the display to the Setup menu. The
green light indicates that the printer is ready. If
the light is blinking, the printer is receiving data.
6. Alphanumeric key pad Use to enter letters and numbers for names and
phone numbers.
7. Clear All button Clears all text or numbers or instructions.
8. Power Saver button This light is on in power saver mode. Push the
button to exit power saver mode.
9. Stop button Cancels the current print job.
10. Start button Press to start a copy, scan, or fax job.
11. Error LED The red light indicates an error condition.
12. Speed Dial button Press to access directories of group or individual
fax telephone numbers.
13. Clear button Deletes a single character each time the button
is pressed. For use when entering email
addresses and telephone numbers.
14. Redial/Pause button Press the button to recall the last fax number
used or to insert pauses in fax numbers.
15. Manual Dial button When faxing, press this button to enter a fax
number with the alphanumeric key pad.
16. Address Book button Press to access the Fax and Email address books.
17. OK button Press to accept the setting selected.
18. Exit button Press to go up one level in the menu.
19. Arrow LEDs These LEDs indicate the flow of data either into
or out of the printer.
20. Job in Memory LED When illuminated, it indicates that there is a job
in the printer’s memory.
21. Color Mode button Press to switch between Color and Black and
White modes for your copy, fax, and scan job.
22. One touch keypad Use to dial stored speed-dial numbers.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
