Xerox Phaser 6128MFP Service Manual

4-70 Phaser 6128MFP Service Manual
General Troubleshooting
7 Check the paper condition
Is the paper dry and approved paper?
Go to step 9. Replace the
paper, then
go to step 8.
8 Check for noise when the paper is fed
into the feed slot
Does the noise come from the printer?
Go to step 9 Complete
9 Perform the Main Motor test (page 4-41):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Does the noise arise from the printer?
Go to step
10.
Go to step
16.
10 1. Reseat the Imaging Unit.
2. Perform the Main Motor test
(page 4-41): Service Mode > Engine
Diag > Motor Test > Main Motor
FULL2.
Is the noise still present?
Go to step
11.
Complete
11 1. Reseat the Transfer Belt connectors.
2. Perform the Main Motor test
(page 4-41): Service Mode > Engine
Diag > Motor Test > Main Motor
FULL2.
Is the noise still present?
Go to step
12.
Complete
12 Check for dirt or debris on the registration
rollers?
Clean the
rollers, then
go to step
13.
Go to step
14.
13 Check for noise when printing
Is the noise still present?
Go to step
14.
Complete
14 Check registration roller rotation.
1. Start the Main Motor test (page 4-41):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2, and while
the motor is running start the Regi
Clutch test: Service Mode > Engine
Diag > Motor Test > Regi Clutch.
Is the noise coming from the Roller(s)?
Replace the
Registration
Roller
Assembly
and/or Metal
Registration
Roller.
Go to step
15.
15 1. Reseat the Main Drive Assembly.
2. Perform the Main Motor test
(page 4-41): Service Mode > Engine
Diag > Motor Test > Main Motor
FULL2.
Is the noise still present?
Try replacing
one after
another:
■ Imaging
Unit
(page 8-8)
■ Transfer
Belt
(page 8-103)
■ Main Drive
Assembly
(page 8-58).
Complete
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
