Xerox Phaser 6128MFP Service Manual

5-40 Phaser 6128MFP Service Manual
Print-Quality Troubleshooting
6 Open and close the Front Cover.
Does the mis-registration (color
shift) appear on the print?
Go to step 7. Complete
7 Reseat the Imaging Unit.
Does the mis-registration (color
shift) appear on the print?
Go to step 8. Go to step 8.
8 Open and close the Front Cover to
reseat the Transfer Belt.
Does the mis-registration (color
shift) appear on the print?
Go to step 8. Complete
9 Set the printer to adjust the color
registration automatically: Menus >
Admin Menu > Maintenance Mode
> Automatic Registration Adjust.
Does the mis-registration (color
shift) appear on the print?
Go to step 9. Complete
9 Adjust the color registration
manually: Menus > Admin Menu >
Maintenance Mode > Adjust Color
Registration.
Does the mis-registration (color
shift) appear on the print?
Go to step 10. Complete
10 Replace the Imaging Unit
(page 8-8).
Is the image printed correctly?
Go to step 11. Complete
11 Replace the Transfer Belt
(page 8-103).
Does the mis-registration (color
shift) appear on the print?
Go to step 12. Complete
12 Replace the MCU Board (page 8-57).
Does the mis-registration (color
shift) appear on the print?
Replace the
printer.
Complete
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
