8-16 Phaser 6128MFP Service Manual
Service Parts Disassembly
7. Disconnect P/J5301 and release the harness from the chassis.
8. Release the Transfer Belt bosses from the guides in the Front Cover and
remove the cover.
s6128mfp-187
1
2
2
P/J5301
