Xerox Phaser 6128MFP Service Manual

24 Phaser 6128MFP Service Manual
General Information
The job is stored in the memory and multiple copies are printed. When the entire
job does not fit in the memory, the printer prints one copy up to the stored pages,
and the remaining are discarded.
An error message will appear on the Control Panel: “Error xxxx Press set key.”
Two options are available to ensure Job Collation will process effectively:
• Break large print job into multiple small print jobs
• Increase memory for the printer
Secure Print
When memory is expanded to 256 MB or more, the printer holds print data,
including a User Password (11 digits), User Name, and Document Name in the
memory.
• User ID – consists of a variable length from 1 to 24 byte characters (20H-
FFH). The driver requests the User ID from the user when the Secure Print
option is selected. A user ID cannot be blanked with only space characters.
• User Password – consists of a variable length from 0 to 11 digits. The
password is an optional input and hidden from the user interface by displaying
“*” for each digit. If a password is not specified, the driver will accept it as a
zero-length string so that a password will not be required when requesting job
output from the printer.
• Document Name – consists of a variable length from 0 to 24 characters (20H-
FFH) that specifies the document name.
The data will not be printed until the same password, user name, and document
name are provided via the printer menu on the Control Panel. User can remove or
keep the data after printing the document. The data remains in the printer
memory as long as it is not cleared and will be cleared when the printer is turned
off. User can omit entering a password (this is called Store Print - not available for
MAC OS 10.2.).
Proof Print
Proof Print can be selected only when multiple sets of prints are specified in the
printer driver. Proof Print requires at least 256 MB of memory. The printer prints
only the first set of the print data including a user name and document name
specified in the printer driver. User can keep or remove the data using the printer
menu on the Control Panel. The data remains in the printer memory as long as it is
not cleared and erased when the printer is turned Off. This function is not available
for MAC OS 10.2 and Linux operating systems.
Form Overlay
The function for writing PCL6 forms are downloaded into RAM Disk.
Font Download
PCL6 fonts can be downloaded into RAM Disk.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
