8-104 Phaser 6128MFP Service Manual
Service Parts Disassembly
10. Tilt the Transfer Belt slowly.
11. Remove the Pivot Kit (page 8-100).
12. Remove the Front Cover Pivot Shaft holding the Transfer Belt in the chassis
and remove the Transfer Belt.
Replacement Note
Reset the Transfer Belt life counter in after installing a new Transfer Belt.
s6128mfp-242
P/J281
