Phaser 6128MFP Service Manual 9-5

Parts List

Parts List 3.2 Feeder

Item Parts name Part number

1 Chute Assy Fdr Regi (With 2-16,20-33) —

2 Shaf Assy Feed —

3 Roll Core Msi —

4 Roll Assy Feed 657K81230

5 Bearing Earth —

6 Actuator Regi Out —

7 Spring Regi Out —

8 Actuator Regi Roll —

9 Roll Assy Regi —

10 Roll Regi Metal —

11 Actuator Regi In 120E27820

12 Spring Act Regi —

13 Sensor Photo 130E87090

14 Actuator SSI (Manual Feed) 120E27850

15 Spring Act SSI —

16 Spring Stp —

17 Stopper Act —

18 Spring Act Np —

19 Actuator No Paper —

20 Bearing M Earth —

21 Bearing Earth Regi —

22 Gear Regi R —

23 Gear Regi M —

24 Spring Regi R M —

25 Plate Earth Regi —

26 Chute Up —

27 Chute Low —

28 Bracket SNS —

29 Spring Regi L M —

30 Bearing M —

31 Bearing R —

32 Actuator Assy No Paper (With 17-19) 120K92294

33 Plate Weight —
