Phaser 6128MFP Service Manual 9-7

Parts List

Parts List 4.1 Xerographics

No. Name/Description

Part

Number

ROS Assy (Laser Unit)

a. Use PL4.1.99, Laser Unit kit, when ordering the Laser Unit.

2 Spring Ros —

3 Holder Crum —

4 Spring PHD —

5 Lever PHD —

6 Block Stopper PHD D —

7 Block Stopper PHD AD —

8 Led Assy Erase 122K94041

9 Spring Tracking —

10 Spring Cf —

11 Spring Tr4 —

12 Spring Tr3 —

13 Spring Tr2 —

14 Spring Tr1 —

15 Spring D4 —

16 Spring D3 —

17 Spring D2 —

18 Spring D1 —

21 PHD Assy (Imaging Unit) 675K69240

22 Harn Assy ROS Re (J40-j411) —

23 Harn Assy ROS Video (J41-j412) —

97 Kit Block PHD Right (With 4,5,7 × 2pcs) 675K54241

98 Kit Block PHD Left (With 4,5,6 × 2pcs) 675K54251

99 Kit ROS (With 1,2 × 2pcs) (Laser Unit Kit) 604K43050
