Phaser 6128MFP Service Manual 9-9
Parts List
Parts List 5.1 Dispenser
ID No. Name/Description Part Number
1 Dispense Assy (With 2,9-11,14-16,25-27) 094K92290
2 Frame Assy Mot (With 3-8) —
3 Motor Assy Disp —
4 Conductor Motor —
5 Frame Motor —
6 Gear Idler —
7 Gear Idler Aug —
8 Gear Idler Agi —
9 Switch (R Side Door) 110E10200
10 Housing Assy Auger —
11 Frame Assy Disp (With 12,13) —
12 Frame Disp —
13 Seal Disp Aug —
14 Connector Crum —
15 Spring Disp —
16 Joint Assy Disp —
17 Holder TCRU K 604K44920
18 Holder TCRU C 604K44930
19 Holder TCRU M 604K44940
20 Holder TCRU Y 604K44950
21B Toner Cartridge US/EU 2.5k (K) 675K59231
21C Toner Cartridge DMO 2.5k (K) 675K59311
22B Toner Cartridge US/EU 2k (C) 675K59241
22C Toner Cartridge DMO 2k (C) 675K59321
23B Toner Cartridge US/EU 2k (M) 675K59251
23C Toner Cartridge DMO 2k (M) 675K59331
24B Toner Cartridge US/EU 2k (Y) 675K59261
24C Toner Cartridge DMO 2k (Y) 675K59341
25 Harn Assy Tnr Mot (J18,J19-J181,J182,J191,J192) —
26 Harn Assy Toner Crum (J31-J311,J312,J313,J314) —
27 Harn Assy Side SW (J29-J291) —
28 —
29 Label Holder —
