Phaser 6128MFP Service Manual 9-11
Parts List
Parts List 6.1 Transfer & Fuser
ID No. Name/Description Part Number
1A
1B
Fuser 115V
Fuser 220V
675K65653
675K65663
2 Harn Assy Fuser (J17,J47-P171) —
3 Stopper Pivot —
4 Pivot Trans L —
5 Gear T4 —
6 Shaft Assy Pivot —
7 Transfer (Unit) Belt 848K03270
8 Cover Harness 2 —
99 Kit Pivot (with 3-6) 675K54121
To Next Page
