Phaser 6128MFP Service Manual 9-17
Parts List
Parts List 10.2 Front Cover
Item Parts name Part Number
1 Cover Assy Front (With 2,3,5-13) 848K27329
2 Console Assy Panel (Control Panel) 848K26097
3 Cover Front
4 Cover Inner Front
5Latch Front
6Plate Latch
7 Spring Latch Out
8 Button Latch
9 Cover Harness
10 Guide Belt R
11 Damper Front L Aio
12 Damper Front S
13 Harness A-op-opp (J202-J5301)
14 Shaft Pivot
99 Kit Shaft Pivot 675K54051
To Next Page
