Phaser 6128MFP Service Manual 9-19

Parts List

Parts List 10.3 Media Tray

ID No. Name/Description

Part Number

1 Cassette Assy 250 (With 2-19) (Tray) 050K64020

2 Plate Assy Bottom —

3 Spring N/f L —

4 Spring N/f R —

5 Separator Roller Assembly 675K81220

6 Guide Side L —

7 Gear Pinion —

8 Guide Side Assy R —

9 Cover Ssi —

10 Guide Side Ssi L —

11 Rack Guide Side Ssi L —

12 Rack Guide Side Ssi R —

13 Guide Side Ssi R —

14 Latch Bottom L —

15 Latch Bottom R —

16 Spring Latch B —

17 Tray Assy Extension —

18 Housing Cst 250 —

19 Handle Cst AIO —
