Phaser 6128MFP Service Manual 9-21
Parts List
Parts List 10.4 Feeder
Item Parts name Part Number
1 Clutch Assy Drv —
2 Bearing Regi —
3 —
4 Chassis Fdr R —
5 Foot —
6 —
7
8 Chassis Fdr L —
9 Bearing —
10 Stopper CST 003E73341
11 Solenoid Feed MSI —
12 Spring Lever —
13 Lever Feed —
14 Spring Feed In —
15 Spring Feed Out —
16 Gear Feed Out —
17 Gear Feed In —
18 Harn Assy L Side (J23,J28-P231,J232,J233,J234,J281) 962K57541
19 Gear Assy Feed (With 15,16) Gear Kit (With 16, 17)
20 Sensor, Temp Humidity
21 Harn Assy Temp Humidity
22 Plate Earth FDR
23 Arrester ENE 112d-10a
24 Plate Earth CST
97 Feeder Assy V AIO (with 4-6, 8-15, 18-24, PL3.2.1) 059K56390
98 Kit Solenoid Feed (With 9-14) 675K54150
99 Kit Clutch Assy Drv (With 1,2) 675K54230
