Phaser 6128MFP Service Manual 9-33
Parts List
Parts List 10.10 ADF
Item Part Name Part Number
1 ADF Assy (With 2,6-8,11-23) 059K61840
2Cover ADF Jam
3 Roll Assy Feed 059K61850
4 Pad Assy Separator 019K10390
5- -
6 Feeder Assy ADF (With 3,4)
7 Harn Assy ADF (J1003-jadf1)
8 Cover ADF Rear (With 9)
9 Arm Interlock
10 - -
11 Tray Assy ADF Input 050K63720
12 Cover Roll Exit
13 Roll Fin Exit
14 Roll Pinch Exit
15 Shaft Roll Exit
16 Spring Roll Exit
17 Cover ADF Base
18 Output Tray Extension
19 Cover Tray Extension
20 Cover ADF Front
21 Cushion ADF Platen
22 Counter Balance L
23 Counter Balance R
98 Kit Feed roll and Pad (with 3, 4 and
instruction sheet)
604K52220
